| Picture number |
Part Name |
Specification |
Size |
Quantity |
Coding |
Drawing number |
| 1 |
Radiographic Ruler |
Development template |
9-12 |
1 |
90002201 |
GA3X01 |
| 2 |
Guide Wire 3.2 mm |
Thread guide pin |
3.2×400 |
5 |
90002003 |
GA1X03 |
| 3 |
Hand Reamer |
Hard expansion |
9 |
1 |
90002025 |
GA1X25 |
| 4 |
Flexible Ream Shaft |
Soft expansion tool bar is rotating forward |
8.5-14 |
1 |
90002204 |
GA3X0500 |
| 5 |
Opening Drill Bit , cannulated |
Proximal Hollow Drill |
14 |
1 |
90002203 |
GA3X04 |
| 6 |
Protection Sleeve |
Inlet guide tube |
|
1 |
90002601 |
GA8X01 |
| 6 |
Handle for Protection Sleeve |
Channel handle |
|
1 |
90002602 |
GA8X0200 |
| 7 |
Gripper |
Guide pin holder |
117 |
1 |
90002050 |
GA1X4100 |
| 8 |
Connection Screw, cannulated |
Connecting bolt |
M8×0.75 |
2 |
90002218 |
GA3X09 |
| 9 |
Rod Pusher for Reaming Rod with Hexagonal Screwdriver |
Ball handle wrench |
SW6.5 |
1 |
90002217 |
GA3X0800 |
| 10 |
Insertion Handle for Nail |
Handle |
|
1 |
90002219 |
GA3X10 |
| 11 |
Multihole Drill Sleeve |
Cellular locator |
17/3.2 |
1 |
90002603 |
GA8X0300 |
| 12 |
quick coupling |
Adapter |
85 |
1 |
90002056 |
GA1X4700 |
| 13 |
T-Handle with quick coupling |
Quick change handle |
92 |
1 |
90002055 |
GA1X4600 |
| 14 |
Reduction Instrument for Medullary Nails |
Reset rod |
7 |
1 |
90002016 |
GA1X1600 |
| 15 |
Reamer Head, 8.5 mm dia. |
Soft expansion head 8.5 |
8.5 |
1 |
90002205 |
GA3X06 |
| 15 |
Reamer Head, 9 mm dia. |
Soft expansion head 9 |
9 |
1 |
90002206 |
GA3X07 |
| 15 |
Reamer Head, 9.5 mm dia. |
Soft expansion head 9.5 |
9.5 |
1 |
90002207 |
GA3X07 |
| 15 |
Reamer Head, 10 mm dia. |
Soft expansion head 10 |
10 |
1 |
90002208 |
GA3X07 |
| 15 |
Reamer Head, 10.5 mm dia. |
Soft expansion head 10.5 |
10.5 |
1 |
90002209 |
GA3X07 |
| 15 |
Reamer Head, 11 mm dia. |
Soft expansion head 11 |
11 |
1 |
90002210 |
GA3X07 |
| 15 |
Reamer Head, 11.5 mm dia. |
Soft expansion head 11.5 |
11.5 |
1 |
90002211 |
GA3X07 |
| 15 |
Reamer Head, 12 mm dia. |
Soft expansion head 12 |
12 |
1 |
90002212 |
GA3X07 |
| 15 |
Reamer Head, 12.5 mm dia. |
Soft expansion head 12.5 |
12.5 |
1 |
90002213 |
GA3X07 |
| 15 |
Reamer Head, 13 mm dia. |
Soft expansion head 13 |
13 |
1 |
90002214 |
GA3X07 |
| 16 |
Awl , cannulated |
Hollow hole opener |
4.2 |
1 |
90002005 |
GA1X0500 |
| 17 |
Protection Sleeve, 12/8 |
Outer casing 12/8 |
12-8 |
2 |
90002227 |
GA3X18 |
| 17 |
Drill Bit Sleeve,8/4.3 |
Drill sleeve 8/4.3 |
8/4.3 |
2 |
90002228 |
GA3X19 |
| 17 |
Trocar,4.3 |
Trocar 4.3 |
4.3 |
1 |
90002229 |
GA3X20 |
| 18 |
Screwdriver, hexagonal with spherical head |
Connecting bolt universal wrench |
SW6.5 |
1 |
90002106 |
GA2X0600 |
| 19 |
Connector, for Insertion Handle |
Driver |
SW11/M8 |
1 |
90002202 |
GA3X0200 |
| 20 |
Aiming Arm |
Proximal sight |
|
1 |
90002220 |
GA3X1100 |
| 21 |
Protection Sleeve, 11.5/8.5 |
Outer casing 11.5/8.5 |
11.5/8.5 |
2 |
90002221 |
GA3X12 |
| 21 |
Guild Pin Sleeve,8.5/3.2 |
Guide needle cannula 8.5/3.2 |
8.5/3.2 |
2 |
90002222 |
GA3X13 |
| 21 |
Trocar 3.2mm |
Trocar 3.2 |
3.2 |
1 |
90002223 |
GA3X14 |
| 22 |
Drill Bit,4.3,Long |
Long bone drill 4.3 |
4.3 |
2 |
90002231 |
GA3X22 |
| 23 |
Hammer Guide Shaft |
Sliding hammer guide rod |
M12/10 |
1 |
90002156 |
GA2X56 |
| 24 |
Depth Gauge for Locking Screws, |
Lock nail depth sounder |
20-100 |
1 |
90002230 |
GA3X2100 |
| 25 |
Direct Measuring Device for Guide Pin |
Guide pin depth sounder |
40-130 |
1 |
90002224 |
GA3X15 |
| 26 |
Reamer(Fixation Sleeve for Reamer) |
Proximal limit step drill |
6.5/4.5 |
1 |
90002225 |
GA3X1600 |
| 27 |
Sliding Hammer |
Sliding hammer |
260 |
1 |
90002073 |
GA1X6400 |
| 28 |
Compression Screw |
Pressure bolt |
M6 |
1 |
90002226 |
GA3X17 |
| 29 |
Screwdriver Stardrive, T25 |
Lock nail wrench T25 |
T25 |
1 |
90002232 |
GA3X2300 |
| 30 |
Screwdriver Stardrive Shaft, T25 |
Lock nail wrench lever T25 |
T25 |
1 |
90002233 |
GA3X24 |
| 31 |
Ream 6.0 |
Flat drill 6.0 |
|
1 |
90002240 |
GA3X31 |
| 32 |
Drill Bit 6.0 |
Bone Drill 6.0 |
|
1 |
90002241 |
GA3X32 |
| 33 |
Reamer 3.4/6.0 |
Step drill 3.4/6.0 |
|
1 |
90002242 |
GA3X33 |
| 34 |
Direct Measuring Device for Drill Bits |
Sounder 4.5 |
150 |
1 |
90002108 |
GA2X08 |
| 35 |
Drill Bit,4.3 |
Bone Drill 4.3 |
150 |
2 |
90002148 |
GA2X48 |
| 36 |
Handle with quick coupling |
AO type quick change handle |
|
1 |
90002155 |
GA2X5500 |
| 37 |
Pin Wrench |
Small wrench |
4 |
1 |
90002103 |
GA2X03 |
| 38 |
Combination Wrench |
Open-end wrench |
SW11 |
1 |
90002102 |
GA2X02 |
| 39 |
Handle for Expander Spacer |
Auxiliary positioning rod holder |
268 |
1 |
90002248 |
GA3X3900 |
| 39 |
ConnectingScrew of Expander Space |
Auxiliary positioning rod holding rod |
265 |
1 |
90002249 |
GA3X4000 |
| 40 |
Expander Wire for Expander Spacer |
Auxiliary positioning rod inner core |
328 |
1 |
90002250 |
GA3X4100 |
| 41 |
L-Curette for Anterior Nail Contact |
L-shaped spatula |
155 |
1 |
90002117 |
GA2X17 |
| 42 |
L-space , adjustable |
Adjustable positioning rod |
9-12 |
1 |
90002243 |
GA3X3400 |
| 43 |
Space Shaft,9 |
Positioning rod 9 |
9 |
1 |
90002244 |
GA3X35 |
| 44 |
Space Shaft,10 |
Positioning rod 10 |
10 |
1 |
90002245 |
GA3X36 |
| 45 |
Space Shaft,11-12 |
Positioning rod 11-12 |
11-12 |
1 |
90002246 |
GA3X37 |
| 46 |
|
|
|
|
|
|
| 47 |
Extraction Screw |
Pull bolt |
M8×0.75 |
1 |
90002257 |
GA3X48 |
| 48 |
Aiming Beam for Locking, 340-420 |
Guide rod 340-420 |
340-420 |
1 |
90002236 |
GA3X2700 |
| 49 |
|
|
|
|
|
|
| 50 |
Expander Spacer,9 |
Auxiliary positioning rod 9 |
9 |
1 |
90002251 |
GA3X42 |
| 51 |
Expander Spacer,10 |
Auxiliary positioning rod 10 |
10 |
1 |
90002252 |
GA3X43 |
| 52 |
Expander Spacer,11-12 |
Auxiliary positioning rod 11-12 |
11-12 |
1 |
90002253 |
GA3X44 |
| 53 |
Sspace Block |
Positioning card block |
|
1 |
90002247 |
GA3X3800 |
| 54 |
Aiming Arm for Distal Locking |
Remote sight |
|
1 |
90002254 |
GA3X45 |
| 55 |
Aiming Arm for Dynamic Locking |
Dynamic hole sight |
|
1 |
90002255 |
GA3X4600 |
| 56 |
|
|
|
|
|
|
| 57 |
Extraction Hook |
Guide needle with hook |
2.8 |
1 |
90002015 |
GA1X15 |
| 58 |
Screwdriver Stardrive, cannulated |
End cap hollow wrench |
SW4 |
1 |
90002064 |
GA1X5500 |
| 59 |
Screwdriver, hexagonal with spherical head |
Tail cap universal ball wrench |
SW4 |
1 |
90002079 |
GA1X6900 |
|
Insrument Set Box |
|
|
1 |
90002258 |
GA3X-0100-XH |
|
Ream Head Box |
(GA1X8400) |
|
|
|
|
